AWG#10(5.5sq)~AWG#32(0.03sq)
🔶Belt-feeding ensures
stable length measurement.
🔶Based on the C371G, the wire is fed using a belt feed system, which allows it to grip cables with uneven surface, reducing damage to the coating.
The photo shows the model equipped with options.
=Casting G model=
●The operability of the touch panel has been improved:
▶Easy to input a wire diameter with the assistance function loaded.
▶Display operating information, not only a number of pieces processed
but also operating time, number of cuts, and blade replacement notifications.
●The control board and power supply system have been completely redesigned to improve reliability.
●Thick wire mode is loaded. *Reduces processing defects caused by insufficient stripping of insulation when processing thick wire.
●Power consumption is reduced by up to 15%, making it environmentally friendly. *Compared to C371A
●Standardized maintenance parts allow for long-term use with peace of mind.
●Noise from the cooling fan has been reduced, improving quietness.
●Supports 10 languages (Japanese, English, Simplified Chinese, Traditional Chinese, Korean, Turkish, Polish, Indonesian, Thai, and Vietnamese).
▪The input power supply is also compatible with worldwide power supplies (AC100V to 240V).
▪ In addition to cutting, stripping, semi-stripping, step stripping, and divided stripping, various other processes such as slitting and intermediate stripping can be performed by equipping options.
Product |
|
Model |
C381G |
External Dimensions | W 450mm × D 440mm × H 290mm |
Weight | 30kg |
Power Supply | AC100V-240V (single phase) 50Hz/60Hz |
Power Consumption (100V) | 27W (rated) 111W (maximum) |
Air Source | 7Nℓ/min *Use clean, dry air |
Processing Dimensions | |
Cutting Length | 0.1mm to 99,999mm |
Cutting Tolerance | ± (0.1+0.0005×L) mm *L = cutting length |
Stripping Length |
Leading edge: 0.1~47.9mm, Trailing edge: 0.1~47.9mm *On short wire mode *It depends on the wire material |
Processable Wire | |
Type | AVSS, VSF, IV, KV, UL, Teflon, glass wire etc. |
Size | AWG#8(8sq)~AWG#28(0.08sq) *It depends on the wire material |
Outer Diameter Size | Maximum φ11mm *It depends on the wire material |
Product |
|
Model |
C381G |
External Dimensions | W 450mm × D 440mm × H 290mm |
Weight | 30kg |
Power Supply | AC100V-240V (single phase) 50Hz/60Hz |
Power Consumption (100V) | 27W (rated) 111W (maximum) |
Air Source | 7Nℓ/min *Use clean, dry air |
Processing Dimensions | |
Cutting Length | 0.1mm to 99,999mm |
Cutting Tolerance | ± (0.1+0.0005×L) mm *L = cutting length |
Stripping Length |
Leading edge: 0.1~47.9mm, Trailing edge: 0.1~47.9mm *On short wire mode *It depends on the wire material |
Processable Wire | |
Type | AVSS, VSF, IV, KV, UL, Teflon, glass wire etc. |
Size | AWG#8(8sq)~AWG#28(0.08sq) *It depends on the wire material |
Outer Diameter Size | Maximum φ11mm *It depends on the wire material |
Mid Stripping Unit
It can handle wires with an outer diameter of up to 8mm. It can mid strip in up to 10 different positions on a single wire. Automation has been accomplished thus far by this revolutionary equipment.
