NEW MODEL ▶ Casting C371G
AWG#8(8sq)~AWG#28(0.08sq)
Standard model C371G balances high speed and high power!
＝Casting G model＝
●The operability of the touch panel has been improved:
▶Easy to input a wire diameter with the assistance function loaded.
▶Display operating information, not only a number of pieces processed
but also operating time, number of cuts, and blade replacement notifications.
●The control board and power supply system have been completely redesigned to improve reliability.
●Thick wire mode is loaded. *Reduces processing defects caused by insufficient stripping of insulation when processing thick wire.
●Power consumption is reduced by up to 15%, making it environmentally friendly. *Compared to C371A
●Standardized maintenance parts allow for long-term use with peace of mind.
●Noise from the cooling fan has been reduced, improving quietness.
●Supports 10 languages (Japanese, English, Simplified Chinese, Traditional Chinese, Korean, Turkish, Polish, Indonesian, Thai, and Vietnamese).
▪The input power supply is also compatible with worldwide power supplies (AC100V to 240V).
▪ In addition to cutting, stripping, semi-stripping, step stripping, and divided stripping, various other processes such as slitting and intermediate stripping can be performed by equipping options.
Specification
|
Product |
|
|
Model |
C371G |
| External Dimensions | W 450mm × D 440mm × H 290mm |
| Weight | 30kg |
| Power Supply | AC100V-240V (single phase) 50Hz/60Hz |
| Power Consumption (100V) | 27W (rated) 111W (maximum) |
| Air Source | 7Nℓ/min *Use clean, dry air |
| Processing Dimensions | |
| Cutting Length | 0.1mm to 99,999mm |
| Cutting Tolerance | ± (0.1+0.0005×L) mm *L = cutting length |
| Stripping Length |
Leading edge: 0.1~47.9mm, Trailing edge: 0.1~47.9mm *On short wire mode *It depends on the wire material |
| Processable Wire | |
| Type | AVSS, VSF, IV, KV, UL, Teflon, glass wire etc. |
| Size | AWG#8(8sq)～AWG#28(0.08sq) *It depends on the wire material |
| Outer Diameter Size | Maximum φ11mm *It depends on the wire material |
Downloads
Processing capacity
Processing conditions:
▪Front / Rear strip length 3mm
▪Processing speed 9
▪Thin wire mode
▪Wire: UL1007 AWG#22
| Full Length | Processing Capacity |
| 100mm | 7,100 pcs/hour |
| 200mm |
6,550 pcs/hour |
| 300mm | 6,050 pcs/hour |
| 500mm | 5,300 pcs/hour |
| 800mm | 4,450 pcs/hour |
| 1,000mm | 4,000 pcs/hour |
| 1,500mm | 3,250 pcs/hour |
| 2,000mm | 2,700 pcs/hour |
| 3,000mm | 2,050 pcs/hour |
| 5,000mm | 1,350 pcs/hour |
*These are values measured by Kodera.
Depending on the type of wire or other processing conditions, the values may be lower than those listed.
Options
Mid Stripping Unit
CMS-801A2 can handle wires with an outer diameter of up to 8mm. It can mid strip in up to 10 different positions on a single wire. Automation has been accomplished thus far by this revolutionary equipment.
Flat Cable Slitting Machine
CSL-501, which has been developed as a special optional item only for C371GF, can make slitting processing on the ends of flat cable. This is an automatic slitting machine intended to improve the comfortable performance of C371GF.
