▪The operability of the touch panel has been improved:
▶Easy to input a wire diameter with the assistance function loaded.
▶Display operating information, not only a number of pieces processed
but also operating time, number of cuts, and blade replacement notifications.
▪The control board and power supply system have been completely redesigned to reduce heat generation and improve reliability.
▪Thick wire mode is loaded. *Reduces processing defects caused by insufficient stripping of insulation when processing thick wire.
▪Power consumption is reduced by up to 15%, making it environmentally friendly. *Compared to C370A
▪Standardized maintenance parts allow for long-term use with peace of mind (same as C370A).
▪Noise from the cooling fan has been reduced, improving quietness.
▪Supports 10 languages (Japanese, English, Simplified Chinese, Traditional Chinese, Korean, Turkish, Polish, Indonesian, Thai, and Vietnamese).
▪The input power supply is also compatible with worldwide power supplies (AC100V to 240V).
Processing conditions:
▪Core diameter: 0.8 mm
▪Blade return: 0.2 mm
▪Front / Rear strip length 3mm
▪Processing speed 9
▪Thin wire mode
▪Program G011
Full Length | Processing Capacity |
50mm | 10,700 pcs/hour |
100mm | 10,000 pcs/hour |
200mm |
8,800 pcs/hour |
300mm | 8,200 pcs/hour |
500mm | 7,300 pcs/hour |
800mm | 6,200 pcs/hour |
1,000mm | 5,700 pcs/hour |
1,500mm | 4,700 pcs/hour |
2,000mm | 4,000 pcs/hour |
3,000mm | 3,000 pcs/hour |
*These are values measured by Kodera.
Depending on the type of wire or other processing conditions, the values may be lower than those listed.
Product |
|
Model |
C370G |
External Dimensions | W450 × D455 × H295mm |
Weight | 30kg |
Power Supply | AC100V-240V (single phase) 50Hz/60Hz |
Power Consumption (100V) | 25Wh in standby mode, 125Wh in operation |
Air Source | 7Nℓ/min *Use clean dry air |
Processing Dimensions | |
Cutting Length | 0.1mm to 99,999mm |
Cutting Tolerance | ± (0.1+0.0005×L) mm *L = cutting length |
Stripping Length | Front End: 0.1~30mm, Rear End: 0.1~30mm |
Processable Wire | |
Type | AVSS, VSF, IV, KV, UL, Teflon etc. |
Size | AWG#10(5.5sq)~AWG#32(0.03sq) *Depends on the wire material |
Outer Diameter Size | Maximum φ6mm *Depends on the wire material |
Automatic Wire Twisting Unit
CASY-637A can smoothly react to catch up with changes of wire thickness and feeding speed. It is a truly speedy, quiet and precise twisting unit.
